| Brand Name: | Hengcing |
| MOQ: | 200 Square Meters (MOQ) |
| Price: | US$3.90 - 4.50 |
| Payment Terms: | T/T |
Hurricane Strap Compatible ASA Synthetic Resin Roof Tile for Storm Zone Housing Projects
Hurricane zones require the roof to stay tied to the structure; this tile is detailed so metal straps connect purlin to wall without cutting the sheet.
| Product name | HENCING ASA synthetic resin tile |
| Product color | Brick Red, Purplish Red, Dark Green,Bule,Grey |
| Length | Customized |
| Product thickness | 2.5mm/2.8mm/3.0mm |
| Product hight | 30mm |
| Pitch distance | 160mm |
| Efficiency | 960mm |
| Profile | 1050mm |
Product Overview
Product Type: hurricane strap compatible ASA resin roof tile
Connection: strap passes under the tile at the fixing line
Fixing: defined screw pattern for storm zone uplift
Edge Detail: barge and ridge trims tied to the frame
Testing: assembly uplift data available
Projects: hurricane zone housing, coastal townships, island buildings
Key Characteristics
1. Continuous Load Path
Straps run from the wall top plate to the purlin under the tile, so uplift force never relies on the sheet alone.
2. Storm Fixing Pattern
Screw spacing is set for the local wind zone, with closer fixing at edges and corners.
3. Trim Restraint
Barge and ridge trims are mechanically tied, which is where most storm failures begin.
Key Features
1. Code Friendly
Connection detail is easy to show on permit drawings.
2. No Special Sheet
Standard tile is used, only the fixing plan changes.
3. Fast Repair
Storm damaged sheets are replaced without touching the straps.
Applications
